NIDEC TAKISAWA TF-SERIES
The Nidec TAKISAWA TF-Series is a high-rigidity, 4-axis CNC turning lathe engineered for efficient machining of long shafts, cylindrical components, and flange-shaped workpieces. Its single-spindle, dual-turret configuration enables flexible cutting approaches to reduce machining time and support consistent production.
With a maximum turning length of 29.53 inches, an NC servo tailstock, and an optional NC Servo Rest, the TF-Series offers a compelling solution for manufacturers producing precision shaft components, including applications in firearm barrel manufacturing.
Designed for productivity and flexibility, the TF-Series combines rigid construction, efficient chip evacuation, and optional shaft-loading automation to support demanding turning operations.
Request A Quote
Specifications
Specifications
| T8 Turret |
|
| Chuck Size |
8" |
| Standard Turning Diameter |
10.24" [9.45" T8] |
| Maximum Turning Diameter |
10.24" |
| Maximum Turning Length |
29.53" |
| Bar Capacity |
2.01" |
| R-Axis Travel [Rest] |
28.35" |
| Spindle Speed |
3200 / 5000 |
| Spindle Horsepower |
20 / 14.7 |
| Turret Type |
Direct Mount |
| Number of Tools |
6 [8] |
| Control |
Fanuc 32i-B |
| Tailstock Drive System |
NC Servo |
| Tailstock Thrust N |
4000 |
| T10 Turret |
|
| Chuck Size |
10" |
| Standard Turning Diameter |
10.24" [9.45" T8] |
| Maximum Turning Diameter |
10.24" |
| Maximum Turning Length |
25.59" |
| Bar Capacity |
3.15" |
| R-Axis Travel [Rest] |
28.35" |
| Spindle Speed |
2500 / 3000 |
| Spindle Horsepower |
20 / 14.7 [Wide Range] |
| Turret Type |
Direct Mount |
| Number of Tools |
6 [8] |
| Control |
Fanuc 32i-B |
| Tailstock Drive System |
NC Servo |
| Tailstock Thrust N |
8000 |
Features
Features
Key Features:
-
Dual-Turret Configuration: Upper and lower turrets provide flexible cutting approaches to improve productivity and reduce machining time.
-
Long-Part Machining Capacity: Maximum turning lengths of 29.53 inches (8-inch chuck) or 25.59 inches (10-inch chuck) accommodate a range of shaft-type components.
-
Optional NC Servo Rest: Provides additional workpiece support for long, slender components during turning operations.
-
Rigid Machine Construction: Rectangular slideways and a vertical bed structure provide a stable foundation for precision turning.
-
Efficient Chip Evacuation: Designed to effectively manage chips generated during shaft and flange machining.
-
Optional Shaft Loader: Supports automated workpiece handling to improve productivity in repetitive production environments.
Applications in Firearm Barrel Manufacturing
The TF-Series' shaft-turning capabilities make it worth considering for manufacturers producing firearm barrels and other long, cylindrical components. Its dual-turret design, available workpiece support, and turning capacity offer potential advantages for barrel exterior machining operations where rigidity, repeatability, and throughput are important.
Contact Yamazen to discuss workpiece dimensions, machining requirements, and available TF-Series configurations for your application.
