COMPACT 5‑AXIS POWERHOUSE – BROTHER SPEEDIO M200Xd1‑5AX

Key Advantages

• High‑Speed Simultaneous 5‑Axis Machining
  Achieve full 5-axis tool-path control with tool center point control (1,000-block look‑ahead), enabling tight tolerances and superior surface finishes.

• Power & Performance
  Dual-purpose spindles: 16,000 RPM milling spindle with 18.9 kW & 2,000 RPM turning spindle (8.7 kW), delivering efficient aluminum-to-steel machining.

• Lightning-Fast Tool Handling
  28-tool magazine, ultra-fast 0.8 s tool-to-tool and 1.4 s chip-to-chip—minimizing idle time.

• Compact Footprint
  Fits in tight shop floors without sacrificing capability—200 × 440 × 305 mm travels and full rotary A/C axes within ~4 m².

Engineered for Complex Tasks

• Integrated Mill-Turn Capability
  The tilting rotary table and turning spindle allow multiple operations in one setup, eliminating handling time and boosting accuracy.

• Robust Axis Clamping
  A-axis clamp torque up to 975 N·m, and a rigid C-axis (345 N·m), for heavy cutting with stability.

• Rapid and Precise Travels
  50 m/min rapid traverse on all axes, with high-acceleration spindles that start/stop in under 0.2 s.

Operator-Friendly Interface

Featuring the CNC‑D00 control—with a 15″ vertical touch display, intuitive apps (tool app, waveform monitor, production stats), and enhanced ergonomics like operator-tilting access.
