Universal OD Grinders
Universal OD Grinders
Universal OD Grinders
Universal OD Grinders

Universal OD Grinders

The GE4i INTER features internal grinding specifications with the same patented Toyoda Stat Bearing and floating plate ball nut technology of external grinding to ensure high accuracy and positioning.

Request A Quote

Specifications

Specifications

Swing Over Table Ø 12.6" (320 mm)
Distance Between Centers 39.4" (1,000 mm)
Grinding Diameter (Max) 11.8 (300) in (mm)
Wheel Surface Speed 8,500 (45) SFPM (m/s)

Swing Over Table Ø 12.6" (320 mm)
Distance Between Centers 59.0" (1,500 mm)
Grinding Diameter (Max) 11.8 (300) in (mm)
Wheel Surface Speed 8,500 (45) SFPM (m/s)

Swing Over Table Ø 12.6" (320 mm)
Distance Between Centers 78.7" (2,000 mm)
Grinding Diameter (Max) 11.8 (300) in (mm)
Wheel Surface Speed 8,500 (45) SFPM (m/s)

Swing Over Table Ø 12.6" (320 mm)
Distance Between Centers 19.69" (500 mm)
Grinding Diameter (Max) 11.8 (300) in (mm)
Wheel Surface Speed 8,500 (45) SFPM (m/s)

Swing Over Table Ø 25.9" (660 mm)
Distance Between Centers 157.4" (1,000 mm)
Grinding Diameter (Max) 25.5 (650) in (mm)
Wheel Surface Speed 6,500 (30) SFPM (m/s)

Swing Over Table Ø 25.9" (660 mm)
Distance Between Centers 98.4" (2,500 mm)
Grinding Diameter (Max) 25.5 (650) in (mm)
Wheel Surface Speed 6,500 (30) SFPM (m/s)

Swing Over Table Ø 25.9" (660 mm)
Distance Between Centers 125.9" (3,200 mm)
Grinding Diameter (Max) 25.5 (650) in (mm)
Wheel Surface Speed 6,500 (30) SFPM (m/s)

Swing Over Table Ø 25.9" (660 mm)
Distance Between Centers 157.4" (4,000 mm)
Grinding Diameter (Max) 25.5 (650) in (mm)
Wheel Surface Speed 6,500 (30) SFPM (m/s)

Swing Over Table Ø 12.6" (320 mm)
Distance Between Centers 12.6" (320 mm)
Grinding Diameter (Max) OD: 8.6 (220) ID: 4.7 (120) in (mm)
Wheel Surface Speed 8,850 (45) SFPM (m/s)

Swing Over Table Ø 12.6" (320 mm)
Distance Between Centers 24.8" (630 mm)
Grinding Diameter (Max) OD: 8.6 (220) ID: 4.7 (120) in (mm)
Wheel Surface Speed 8,850 (45) SFPM (m/s)
