Pallet Changing Compact Machining Center Built for Productivity
The Brother SPEEDIO R450Xd1 is a compact, high-performance machining center engineered to maximize throughput and minimize non-cutting time. Equipped with Brother’s original QT Table pallet changer, this machine delivers exceptional productivity by eliminating wasted motion during workpiece changes—keeping spindles cutting and production moving.
Recognized with the iF DESIGN AWARD 2023, the R450Xd1 combines advanced engineering, intelligent control, and efficient machine design to meet the demands of modern manufacturing environments.
QT Table Pallet Changer
High Productivity Without Compromise
The QT Table is Brother’s proprietary pallet changing system designed to eliminate lift-up motion during pallet exchange. This innovative approach significantly reduces changeover time, allowing for faster cycle completion and improved overall equipment efficiency.
Built for High Productivity
Flexible Tool Magazine Options
The R450Xd1 offers multiple tool magazine configurations—14, 22, or 28 tools—allowing manufacturers to tailor the machine to their production requirements. Combined with Brother’s integrated machine and controller development, the result is overwhelming productivity in a compact footprint.
Machining Capability
From High-Speed to Heavy-Duty Cutting
Designed for versatility, the SPEEDIO R450Xd1 provides a broad range of cutting performance. From high-speed, highly efficient machining to more demanding heavy-duty cutting operations, this machine delivers stable and reliable performance across a wide range of applications.
Advanced NC Control
CNC-D00 Controller with Enhanced Usability
The R450Xd1 is equipped with Brother’s new CNC-D00 controller, featuring a 15-inch LCD touch panel for improved visibility and ease of operation. The intuitive interface enhances operator efficiency while supporting faster setup and smoother production workflows.
Key Specifications at a Glance
- Travels (mm): X: 450 | Y: 320 | Z: 305
- Max Spindle Speed: 10,000 RPM (Optional 16,000 RPM or 10,000 RPM High-Torque)
- Tool Storage Capacity: 14 / 22 / 28 tools
- Pallet Changer: Brother QT Table
- Controller: CNC-D00 with 15” LCD Touch Panel
Designed to Improve Every Production Site
With its compact design, intelligent pallet changing system, and high-performance control, the Brother SPEEDIO R450Xd1 is engineered to improve productivity at every production site—without sacrificing precision or flexibility.
