BROTHER SPEEDIO W1000Xd2

BROTHER SPEEDIO W1000Xd2

Mounting a new 28-tool magazine promotes process integration for machining large workpieces. With maximum table loading capacity increased to 500 kg and increased Z-axis travel, the machine is widely suitable for a variety of production systems.

Request A Quote Tooling Options

Specifications

Specifications

Specification Detail
X Axis Travel 39.4"
Y Axis Travel 19.7"
Z Axis Travel 15.0"
* Spindle RPM 10,000/12,000/16,000
Tapping RPM 6,000
Rapid Traverse 1,969 IPM (2205 Z-Axis)
* Cutting Feed rate X, Y, Z: 1~30,000 (0.04 ~ 1,181)
Table Size 43.3" x 19.7"
Maximum Loading Capacity 661 lbs
ATC Capacity 14/21/28
Tool To Tool Time 0.6/0.7
Chip to Chip Time 1.3/1.4
Tool Shank Type MAS-BT30
Maximum Tool Length 9.8"
Maximum Tool Diameter 4.3"
Maximum Tool Weight 6.6 Lbs
