Matsuura MX-520 PC4: Automated 5-Axis Precision for Modern Manufacturing

The Matsuura MX-520 PC4 is a high-performance, 5-axis machining center engineered to deliver exceptional accuracy, repeatability, and extended unattended operation. Designed to meet the needs of high-mix, high-precision manufacturing environments, the MX-520 PC4 integrates advanced automation and intuitive control into a compact, floor-efficient footprint.

Advanced Automation with Multi-Pallet Capability

The MX-520 PC4 features a 4-pallet system and a 90-tool magazine, enabling continuous, lights-out production. This setup significantly reduces downtime between operations, making it an ideal solution for facilities looking to scale throughput without sacrificing precision.

  • 4 automatic pallets for uninterrupted workflow
  • 90-tool capacity for high-mix part production
  • Travel range (X/Y/Z): 630 / 560 / 510 mm
  • A-Axis tilt range: -125° to +10°
  • C-Axis rotation: full 360°

Precision Spindle Performance

Equipped with a 12,000 rpm spindle delivering 120 Nm of torque, the MX-520 PC4 handles a wide range of materials with ease—from aluminum to hardened steel. Its rigid construction and optimized kinematics ensure stable, precise machining across demanding applications.

MIMS: Intelligent Operation, Simplified

The MX-520 PC4 is powered by Matsuura Intelligent Meister System (MIMS), offering real-time monitoring, diagnostics, and operator guidance. This user-friendly interface reduces learning curves and enhances productivity for operators at every skill level.

Efficient Design, Maximum Compatibility

Designed with space efficiency in mind, the MX-520 PC4 fits seamlessly into production floors of all sizes. It is fully compatible with MAM72-52V pallets, giving users flexibility to scale or integrate with existing Matsuura platforms.

Applications

This machine is ideally suited for:

  • Aerospace component machining
  • Medical device manufacturing
  • Precision engineering and prototyping

Get More from Your Machine Tool Investment

The Matsuura MX-520 PC4 delivers a powerful combination of automation, 5-axis capability, and advanced control technology—making it a smart investment for manufacturers aiming to reduce manual intervention while increasing accuracy and throughput.

Contact us today to learn more or schedule a demo with a Yamazen representative.
